Features Big Booster 2024
Frame: Meybo Booster Aluminium
Fork: Cr-Mo 1 1/8”
Headset: Neco Sealed, Full Integrated 1 1/8”
Handlebar: Cr-Mo 5.75”
Stem: 1 1/8”, 53 mm
Grips: 132 mm, lock-on
Brake Lever: Tektro
Caliper: Tektro 319A-R V-Brake
Front Hub: Sealed, 36H, black
Rear Hub: Sealed Flip-Flop, 36H, black
Spokes: Steel, black
Nipples: Alloy, black
Front Rim: 24 x 1.75”, Double Wall, black
Rear Rim: 24 x 1.75”, Double Wall, black
Tires: Kenda K1121, 24 x 1.95”, White Wall
Seat: Velo VL-7081 Pivotal Vinyl, black — incl. 27.2 mm seatpost
Seat Clamp: 31.8 mm, black
Crankset: Outside Bearing, 175 mm
Bottom Bracket: Outside Sealed Euro Bearing
Pedals: VP Plastic, black
Front Sprocket: 4-hole, 35T
Rear Sprocket: Cog 16T, 3/32”
Chainring Bolts: Cr-Mo
Chain: KMC Z-6
Chain Tensioners: 1-hole, black
Sizing Big Booster 2024
Top Tube Rider Area: 559 mm
Down Tube: 573 mm
Chainstay: 385 mm
Head Tube Angle: 74°
Seat Tube Angle: 70.5°
Head Tube Size: Full Integrated 1 1/8”
Seat Post Size: 27.2 mm
Dropouts: 10 mm
Bottom Bracket: Euro
Brake Compatibility: V-Brake only (no disc option)
Weight: 10,130 g
